PA6T 2.0MM Pitch 2*8P Right Angle Pin Connector UL94V-0

PA6T 2.0MM Pitch 2*8P Right Angle Pin Connector UL94V-0

    • PA6T 2.0MM Pitch 2*8P Right Angle Pin Connector UL94V-0
    • PA6T 2.0MM Pitch 2*8P Right Angle Pin Connector UL94V-0
  • PA6T 2.0MM Pitch 2*8P Right Angle Pin Connector UL94V-0

    Product Details:

    Place of Origin: China
    Brand Name: CNJWY
    Certification: UL/SGS/ROSH/REACH
    Model Number: CN86-XXXXXXXX

    Payment & Shipping Terms:

    Minimum Order Quantity: 2K
    Price: 0.01~0.2
    Packaging Details: Tube/Tray/Reel Packaging
    Delivery Time: 7 to 10days
    Payment Terms: T/T, Western Union, MoneyGram
    Supply Ability: 10000000PCS/Month
    Contact Now
    Detailed Product Description
    Pitch: 2.0MM Height: 2.0MM
    Finish: Au Flash Pin: 16
    Color: Black Pin Lenght: 13mm
    High Light:

    PA6T Right Angle Pin Connector

    ,

    Right Angle Pin Connector UL94V-0

    ,

    2.0MM Pitch Pin Header Connectors

    Pin length Pin Header 2.0MM Pitch 2*8P Gold flash PA6T ROHS REACH Certificated



    •
    • Operation Temperature -40°C to 105°C
      Contact Material Phosphor Bronze
      Contact Plating AU over Ni
      Insulator Material PA6T+30%GF UL94V-0
      Currently Rating 1.0AMP
    • Pin Header connector:

      1.product features: the use of a wide range of environmental protection, high temperature, fire resistance, oxidation resistance.



      2.product material: PA6T/PBT/ brass or phosphor bronze insulation material: plastic UL 94V-0.



      3.scope of application: Widely used in electronics, electrical appliances, instruments in the general connection of the main components of the current or signal transmission. Usually with the needle supporting the use of a board to board connection. The utility model is matched with an electronic wiring harness terminal to form a board to wire connection.

    • ​​Drawing

    PA6T 2.0MM Pitch 2*8P Right Angle Pin Connector UL94V-0 0
