Gray 2 * 07 Ways Flat Ribbon Cable Assembly With 1.27mm Rectangular Connector

    • Gray 2 * 07 Ways Flat Ribbon Cable Assembly With 1.27mm Rectangular Connector
    • Gray 2 * 07 Ways Flat Ribbon Cable Assembly With 1.27mm Rectangular Connector
    • Gray 2 * 07 Ways Flat Ribbon Cable Assembly With 1.27mm Rectangular Connector
  • Gray 2 * 07 Ways Flat Ribbon Cable Assembly With 1.27mm Rectangular Connector

    Product Details:

    Place of Origin: China
    Brand Name: JWY
    Certification: UL/SGS/RoHs
    Model Number: CA127-XXXXXX

    Payment & Shipping Terms:

    Minimum Order Quantity: 500Pcs
    Packaging Details: PE bag/ Cabel tie/customized packaging
    Delivery Time: 7 to 15 working days
    Payment Terms: T/T, Western Union
    Supply Ability: 100000PCS per day
    Contact Now
    Detailed Product Description
    Pitch: 1.27 Connector: IDC Rectangular Connector
    Color: Black Cable: UL 2678 30AWG
    Cable Pitch: 0.635mm Cable Color: Gray
    Testing: 100% Open & Short Test Port: Shenzhen

    Gray Flat Ribbon Cable Assembly With 1.27mm Rectangular Connector Terminal Gold



    Specification:

    Connector 1.27 mm IDC Socket Gray
    Pins available 06Pins to 80Pins
    Number of Row Dual
    Terminal Finish Gold over Nickel
    Cable UL2678 28AWG 0.635mm
    Cable Pins available 06Pins to 100Pins
    Color Gray
    Length Customization
    Style Wire to Board
    Crimp Orientation Same Orientation(First Pin is Red Line)
    Crimp Tools Semi-Automatic Machine
    Test 100% Open & Short Test
    Certificate UL Authentication
    Equivalent Brand TE Connectivity/AMP/FCI/Molex/HRS
    Packaging Single PE Bag
    Shipping method Fedex/DHL/UPS/TNT or Specify Forwarder



    What is the flat ribbon cable assembly



    Ribbon Cable Assemblies,IDC, compliant with RoHs,could be customized,1.0mm,1.27mm,2.54mm pitch all available. They are often used for connections to PCBs and for links either within equipment or externally.Ribbon cables have the best ability both in compactness and manageability. We could also provide all kinds of types needed,such as standard grey, color-coded (rainbow) Ribbon in laminated or edge boded form and specials such as twisted pair (twist-n-flat), round jacketed (round-n-flat) and screened ribbon cables.More and more types of connectors with bigger ranges are available now,including standard IDC sockets, D-types, half-pitch D-types, Centronics, Half-pitch Centronics, plus PCB Dual Inline, card-edge and transition connectors.



    How to distinguish cable direction



    1). Same direction

    Both bump at the same way.

    2). Opposite direction

    Both bump at the oppsite way.

    3). Up and dowm direction

    Both bump at the different way. For the details,you can check as below image description.

    Gray 2 * 07 Ways Flat Ribbon Cable Assembly With 1.27mm Rectangular Connector



    Why Choose CNJWY:

    Research and Development Capability:

    Strong research and development capability on product designing and mould developing makes CNJWY able to evaluate the new product,which could help clients save the time cost.



    OEM/ODM Producing

    CNJWY has our own assembly lines from electroplating,stamping,moulding,injection and packaging.



    Quality Guarantee

    Strictly following the demands of ISO9001-2015,CNJWY is able to produce products of highest quality.



    Competitive Price

    More than 10 years of producing experience,CNJWY is always specializing in improving the production capacity.Competitiveness provides competitive price for the valued customers



    Scope of Application:



    Flat ribbon cable assembly widely used in different industry such as automotive, medical equipment, outdoor led screen and so on. as below image is application scenarios. image is limitation ,for more detail you can directly contact with our sales team

    Gray 2 * 07 Ways Flat Ribbon Cable Assembly With 1.27mm Rectangular Connector
