VGA Combination Input Output Connectors 25 Male 25 Base Black 90 Degree Insert Plate

    • VGA Combination Input Output Connectors 25 Male 25 Base Black 90 Degree Insert Plate
    • VGA Combination Input Output Connectors 25 Male 25 Base Black 90 Degree Insert Plate
  • VGA Combination Input Output Connectors 25 Male 25 Base Black 90 Degree Insert Plate

    Product Details:

    Place of Origin: China
    Brand Name: JWY
    Certification: UL/SGS/ROHS/REACH
    Model Number: DBC50-XXXXXX

    Payment & Shipping Terms:

    Minimum Order Quantity: 1000PCS
    Price: negotiation
    Packaging Details: Plastic box packing
    Delivery Time: 7 to 15 working days
    Payment Terms: T/T, Western Union
    Supply Ability: 10000000PCS
    Contact Now
    Detailed Product Description
    Voltage Resistance: 500V AC R.m.s Contact Resistance: 25 M Omega Max
    Working Temperature Range: -55 ℃~+105℃ Rated Current: 3.0A AC (RMS)
    Insulation Resistance: 1000M Omega Min Material - Resin: PBT UL94V-0

    VGA Combination D-SUB Connector 25 Male + 25 Base Black 90 Degree Insert Plate​






    Product characteristics:

    Rated current 3.0A AC (RMS)
    Working temperature range -55 ℃~+105℃
    Material - metal  copper alloy
    Insulation resistance  1000M Omega Min
    Contact resistance  25 m Omega Max
    Voltage resistance 500V AC r.m.s
    Rated voltage 250V AC (RMS) /DC



    The development of connector technology presents the following features:



    The high speed and digitalization of signal transmission, integration of all kinds of signal transmission, miniaturization of product volume, low cost of product, surface attachment of contact parts, modular combination, convenience of plug and so on, etc. The above technology represents the direction of the development of connector technology, but it needs to be explained that the above technology is not necessary for all connectors, different matching areas and different use of the environment of the connector, the requirements of the above technology are completely different.



    service idea:



    1. the series of product specifications are complete, but also tailor-made.
    2. import equipment and high degree of automation timely delivery. Usually 7-10 days.
    3. strict implementation of the ISO 9000 and ERP system, the supply of materials strictly in accordance with the quality and standard production control. Product quality assurance through UL-certified.
    4. Free sample 15-20 sets, cost-effective, the same quality unit price is very competitive
    5. the quality is safe and reliable, the price is competitive.





    The advantage is:



    1. High-Quality Guarantee

    CNJWY has been focusing on improving the Quality Control Systems, aiming at providing high-quality products that fit ISO9001 Certificate for years.



    2. Competitive Price

    We have a whole set production process which include electroplating,stamping,injection molding,assemly to ensure our competetive price.



    3. Customized Packaging

    All the products are available for customized packaging according to your demand.



    4. Fast Delivery

    Most efficient producing makes fast delivery, which would make sure of the lead time always ahead of your expectation.



    5.The series of product specifications are complete, but also tailor-made. Safe and reliable quality, competitive price.



    The product application area is attached to the following chart:



    VGA Combination Input Output Connectors 25 Male 25 Base Black 90 Degree Insert Plate
