Single Row 2.54MM Pitch Vertical Female Header Connector 02P-40P Gold Flash PA6T Through Hole

CNJWY presents its high-performance Single Row 2.54MM Pitch Vertical Female Header Connector, engineered for reliable board-to-board and wire-to-board interconnect applications across consumer electronics, industrial control systems, and telecommunications equipment. This through-hole mount female socket connector features precision-machined phosphor bronze contacts with gold flash plating over nickel underplate, ensuring reliable conductivity, corrosion resistance, and long-term mating reliability. The vertical orientation provides straightforward PCB layout integration, while the standard 2.54mm (0.1 inch) pitch maintains compatibility with the widest range of mating pin headers in the electronics industry. Available in pin configurations ranging from 02P to 40P, this connector series offers exceptional design flexibility for engineers seeking dependable interconnect solutions in compact PCB assemblies.

• Standard 2.54MM Pitch Design: The industry-standard 0.1 inch pitch ensures universal compatibility with virtually all mating pin headers, IDC connectors, and ribbon cable assemblies, simplifying BOM management and reducing sourcing complexity across multiple product lines.
• Gold Flash Contact Plating: Each phosphor bronze contact receives uniform gold flash plating over a nickel barrier layer, delivering low contact resistance below 20mΩ, enhanced oxidation prevention, and consistent electrical performance across 300+ mating cycles.
• High-Temperature PA6T Insulator: The PA6T thermoplastic housing reinforced with 30% glass fiber achieves UL94V-0 flammability rating and withstands reflow soldering temperatures up to 260°C, making it fully compatible with lead-free PCB assembly processes.
• Single Row Space-Saving Layout: The compact single-row footprint minimizes PCB real estate consumption while providing reliable signal transmission, ideal for designs where board space is at a advanced and pin density requirements are moderate.
• Wide Pin Count Availability: With configurations spanning from 02P through 40P, designers can select the exact pin count needed without compromising on connector quality or performance, reducing both component count and assembly complexity.
• Robust Through-Hole Termination: Through-hole solder termination provides enhanced mechanical strength and vibration resistance compared to surface mount alternatives, ensuring long-term connection integrity in demanding operating environments.

This single row 2.54mm pitch female header connector finds extensive application across diverse electronic industries. In consumer electronics, it serves as the primary interconnect for microcontroller development boards, Arduino-compatible shields, LCD display modules, and home appliance control PCBs. Within industrial automation systems, it connects PLC I/O modules, sensor interfaces, motor driver boards, and process monitoring equipment. The connector is equally suitable for telecommunications infrastructure, including network switches, router backplanes, and fiber-optic transceiver modules. Additional application areas encompass medical diagnostic instruments, LED lighting control systems, automotive dashboard electronics, security surveillance equipment, and educational electronics prototyping platforms. The versatility of this standard-pitch connector makes it a go-to solution for design engineers across nearly every electronics subsector.

CNJWY employs industry-standard packaging methods tailored to customer requirements. Standard bulk packaging uses anti-static tubes (stick magazines) for pin counts up to 40P, with each tube holding 20-50 connectors depending on pin count. For automated pick-and-place assembly lines, tape-and-reel packaging is available upon request. All packaging materials are ESD-safe and moisture-resistant, ensuring connectors arrive in pristine condition. Every production batch undergoes 100% visual inspection, contact resistance testing, and dimensional verification. CNJWY maintains ISO9001:2015 certified manufacturing processes, and our connectors carry UL, SGS, ROHS, and REACH certifications. Standard lead time is 7-10 working days with a minimum order quantity of 2,000 pieces. OEM and ODM customizations including specific pin lengths, insulator colors, and plating thicknesses are fully supported.
