Ultra-Fine 1.0MM Pitch Dual Row Female Header Connector Gold Flash PA6T 04P-80P High Density PCB Socket

CNJWY introduces its cutting-edge Ultra-Fine 1.0MM Pitch Dual Row Female Header Connector, representing the forefront of miniaturized interconnect technology for next-generation portable and wearable electronics. At merely 1.0mm contact pitch, this connector achieves interconnect density approximately 2.5 times greater than traditional 2.54mm connectors, enabling unprecedented PCB miniaturization without sacrificing signal channel count. The precision-engineered phosphor bronze contacts feature gold flash plating for reliable low-level signal transmission, while the PA6T high-temperature thermoplastic housing ensures dimensional stability through lead-free reflow assembly. Dual row configurations from 04P to 80P provide comprehensive design flexibility for applications ranging from compact sensor fusion modules to complex system-on-module interfaces. The SMT termination with optimized lead coplanarity delivers consistent solder joint formation in high-volume automated assembly environments, making this connector the definitive choice for consumer electronics, IoT devices, and medical wearables demanding maximum functionality in minimal space.

• Industry-advanced 1.0MM Miniaturization: At 1.0mm pitch, this connector achieves the highest interconnect density in the CNJWY female header portfolio. A 40-position dual row connector occupies approximately 20mm x 4mm of PCB area, enabling multi-channel signal routing in space-constrained designs such as smartwatches, wireless earbuds, and implantable medical devices.
• Precision-Formed Micro Contacts: Each phosphor bronze contact is precision-stamped to maintain consistent insertion and withdrawal forces despite the miniaturized geometry. The gold flash over nickel plating system ensures stable contact resistance below 30mΩ for low-level analog and high-speed digital signals across hundreds of mating cycles.
• SMT Automated Assembly Ready: The fine-pitch SMT leads are engineered for compatibility with standard 0201 and 0402 component placement processes. Tape-and-reel packaging with precision pocket dimensions and vacuum pickup surfaces enables reliable handling by high-speed chip shooters and multi-function placers from all major equipment manufacturers.
• PA6T Thermal Stability: The glass-fiber-reinforced PA6T insulator maintains precise contact position tolerance through the complete lead-free reflow thermal cycle, ensuring consistent mating alignment with 1.0mm pitch male pin headers after assembly.
• Expanded Signal Channel Count: With dual row configurations extending to 80 positions, designers can route up to 80 discrete signal channels through a single connector pair, dramatically simplifying PCB layout for complex functions including MIPI camera interfaces, parallel display buses, and multi-channel sensor arrays.
• Low-Profile Stacking Solution: The vertical SMT design with mated height as low as 5.0mm enables tight board-to-board stacking in ultra-slim product enclosures, supporting the trend toward thinner smartphones, tablets, and portable medical devices.

The 1.0mm ultra-fine pitch female header connector enables miniaturization across the most demanding electronic applications. Smartphones and tablets utilize these connectors for camera module interfaces, display flex-to-board connections, and sensor hub interconnects. Wearable technology including smartwatches, fitness trackers, and augmented reality glasses rely on the connector's minimal footprint for high-density interconnects within extremely compact enclosures. Medical devices such as continuous glucose monitors, hearing aids, and wearable ECG patches benefit from the connector's reliability in life-critical applications. IoT edge devices including environmental sensor nodes, asset tracking tags, and smart building controllers employ these connectors for modular sensor integration. Drone and robotics applications leverage the high pin count for compact flight controller and motor driver interconnects. Additional applications include solid-state drive (SSD) board stacking, camera gimbal controllers, portable spectroscopy instruments, and miniaturized scientific payloads for CubeSat satellites.

CNJWY 1.0mm ultra-fine pitch connectors are supplied exclusively in tape-and-reel packaging engineered for high-speed automated placement. Standard reel quantities range from 1,000 to 3,000 pieces depending on pin count, with 330mm diameter reels on 16mm or 24mm wide carrier tape. All components ship in moisture-barrier bags with desiccant and HIC indicators, rated to IPC/JEDEC J-STD-020 MSL Level 3. Vacuum-sealed inner packaging with ESD-safe conductive materials protects the fine-pitch leads from mechanical damage during transit. Every production lot undergoes 100% automated optical inspection for lead coplanarity, contact position accuracy, and solder pad integrity. CNJWY maintains ISO9001:2015 certified manufacturing with UL, SGS, ROHS, and REACH compliance. Custom lead frame designs, selective gold plating options, and application-specific insulator colors are supported through our dedicated OEM engineering program. Standard delivery is 7-10 working days with a minimum order quantity of 2,000 pieces.
